Weight: 24kg
Air consumption:≤50L/s
Drilling diameter:34-42mm
Max. drilling depth:5m
Category:Pneumatic Rock Drill
Request For Quotation
  • Introduce

The Y24 Hand Held Rock Drill is a light but robust jackhammer designed for both dry and wet drilling in medium-hard to hard rock. Manufactured from high-strength alloy steel, its durability is enhanced by a four-bolt back head, allowing it to perform reliably even under extreme conditions. This makes the Y24 an ideal pneumatic tool for a range of light to medium-duty applications, from construction and plant maintenance to quarrying.

Y24 Hand Held Pneumatic Rock Drill with operator handle

Key Features & Benefits

High Efficiency: Delivers powerful impact energy (≥27 J) and frequency (≥27 Hz) for fast drilling and effective secondary breaking.

Lightweight & Maneuverable: Weighing approximately 24 kg, it is easy for a single operator to handle, perfect for jobs requiring high mobility.

Robust and Durable: Built to last, with key components forged from alloy steel to withstand tough working environments and ensure a long service life.

Continuous Lubrication: Can be equipped with the FY200B oiler to provide continuous lubrication, protecting internal parts and reducing maintenance.

Technical Specifications of the Y24 Rock Drill

ParameterValueUnit
Weight≈24kg
Length604mm
Cylinder Diameter70mm
Piston Stroke70mm
Working Air Pressure0.4 ~ 0.63Mpa
Impact Frequency≥ 27Hz
Air Consumption≤ 50L/s
Air Hose Inner Diameter19mm
Drill Bit Diameter34 ~ 42mm
Shank Size22 x 108±1mm
Optional: FY200B OilerValueUnit
Capacity200ml

Y24 Portable Jack Hammer Accessories

A full range of accessories and spare parts for the Y24 jack hammer is available to ensure continuous operation and optimal performance.

Exploded view diagram of Y24 portable jack hammer parts and accessories

Operating & Safety Guidelines

Before using your pneumatic rock drill, please follow these essential safety and operational procedures:

Pre-Operation Inspection: Thoroughly check all parts for integrity. Ensure the machine is properly lubricated, air and water lines are clear, and all connections are firm.

Worksite Preparation: Inspect the drilling area for loose rocks or hazards and clear them before starting to prevent slippage.

Adhere to Wet Drilling: Dry drilling is strictly prohibited. Always turn on the water before the air, and shut off the air before the water when stopping.

Proper Drilling Technique: Start at a low speed to establish the hole, then proceed at full speed. For safety, operators should not wear gloves.

Safe Stance: When using an air leg, maintain a secure stance. Never use your body weight to apply pressure and always stand clear of the drill rod's path to prevent injury from a broken rod.
